I Current
I/O- Input/ Output
ID number A 16-bit number that identifies a Profibus product uniquely. It
represents a reference for the GSD file. Several devices
have the same ID number, provided they are described in a common
GSD file. This number is allocated by the Profibus
User Organization.
IEC 61158 Worldwide standard for Profibus DP and FMS. Successor of
international standard EN 50170, Volume 2
IP20 Ingress Protection, 20 = Device protection according to
EN 605291.
IP20 Ingress Protection, 67 = Device protection according to
EN 605291.
LSB Least significant bit
LWL Optical fiber
MSB Most significant bit.
Ni Nickel
PAA Process map of outputs
PAE Process map of inputs
PELV Protective Extra Low Voltage
PNO Profibus User Organization.
Power-LED LED to signal the operating status
Pt 100 Temperature sensor on platinum base (0°C is equivalent to 100)
+R High potential sensor connection.
-R Low potential sensor connection.
Repeater Coupling element to process signals between Profibus segments.
RL Sensor power supply in three-wire mode.
RTD Resistance Temperature Device.
S Reference potential
