Manual Cube67+ | System Manual
41
Segment The internal system connection supports a left and a right segment. Slot
0 and 2 belong to the left segment, slot 1 and 3 to the right segment.
SELV Safety Extra Low Voltage.
Simatic Manager Programming software for program-logic controllers made by Siemens.
PLC Program-logic controller
Line If modules are connected to slot 0, it is called "connected to line 0".
TH Thermoelement / thermocouple.
TH+ High potential sensor connection
TH- Low potential sensor connection.
Type E, Type J, Type K,
Type N, Type R Thermoelements as per DIN EN 60584 standard.
U Voltage
U/I Voltage / current
UA (brown terminal) Actuator supply
UA (red terminal) Module supply
UB Operating voltage
UI (red terminal) Module and sensor supply
US (brown terminal) Sensor supply
VDMA Verband Deutscher Maschinen- und Anlagenbau e.V. (Association of
German Machinery and Industrial Equipment Manufacturers)
VZ Sign.
ZVEI Zentralverband Elektrotechnik- und Elektronikindustrie e.V. (German
Electrical and Electronic Manufacturers' Association).
