Manual Cube67+ | System Manual

3.4.5.3 Cable Break Monitoring

Murrelektronik GmbH supplies the M12 diagnosis adapter with a simple accessory which helps you to

monitor M12 lines to the sensors or actuators of your system for wire break.

Sensor

1 (+)

2 Diagnosis

3 (-)

4 (S)

M12 adapter with jumper

1 (+)

3 (-)

4 (S)

M12 female connector

Fig. 12: Cable Break Monitoring

When using a Desina sensor, no connector with LED in the plug must be connected,

otherwise wire break will not be recognized.
