MUSTOOL MDS8207 User Manual

8
Function buttons and main option menu
The function buttons of F1~F4 are located at the lower of the LCD screen. With the option menu on the screen,
these buttons will enable users to realize several functions. Some functions are provided with sub-option menu for
further operations. Please refer to relevant later sections for the usage of these option menu and optional option
menu.
The main option menu provides the instructions for basic operations of the instrument and the details are as
follows:
Horizontal adjustment
Vertical adjustment
Triggering control
Cursor function
TIME
VOLT
TRIG
CURS
F1
F2
F3
F4
1. Press F1 button (TIME) to enter into sub-option menu of time base setting and adjust the scanning time base and
triggering position
2. Press F2 button (VOLT) to enter into sub-option menu of vertical sensitivity setting and adjusts the vertical
amplitude and waveform position
3. Press F3 button (TRIG) to enter into sub-option menu of trig setting and adjust the trigger level, gradient and
mode.
4. Press F4 button (CURS) to enter into cursors measurement function. This function is valid only after completion
of waveform holding or single-time scanning and is not displayed at other time.
