VJ-1624 QUICK REFERENCE 5 Troubleshooting
5-3
5.1.2 Adjust the print head
It is used for optimizing the quality of image prints.
This printer has the following adjustment methods.
NOTE
• This printer was adjusted at the factory shipment so that it obtains the optimum printing quality.
Adjust the quality if the print quality changes after the installation environment or the media is
changed.
• If you change the user type settings after performing Standard Adjust Print, make sure to perform
Adjust Print.
• When performing Custom adjust print, the print modes are adjusted all at once. Therefore, you do
not need to perform print adjustment even when the user type setting has been newly set or changed.
• When using RIP software, etc, and setting the resolution which is different from the setting in the
user type setting, make sure to perform adjustment for all print modes by Custom Adjust Print.
5.1.3 Standard Adjust Print
Adjusts only the print mode in the user type setting which is currently set.
This menu is made up with the following menus.
Follow the procedure below to adjust print quality.
1. Print the confirmation pattern and check the amount of misalignment.
5.1.3.1 Standard Confirmation Pattern
Adjustment
method
Description Reference
Standard Adjusts only the print mode in the user type setting which is
currently set.
5.1.3 Standard Adjust Print
Custom Adjusts all print modes.
5.1.4 Custom Adjustment Pattern
Menu Name Description Reference
Standard Confirmation
Pattern
Print the confirmation pattern and check the amount
of misalignment.
5.1.3.1 Standard Confirmation
Pattern
Standard Rough
Adjustment Pattern
Perform this adjustment when the misalignment is
big.
5.1.3.2 Standard Rough Adjustment
Pattern
Standard Micro
Adjustment Pattern
Perform this adjustment when the misalignment is
small.
5.1.3.3 Standard Micro Adjustment
Pattern
To Next Page
