VJ-1624 QUICK REFERENCE 3 Basic usage
3-17
3.4.2 Installing 440ml ink cartridges
Follow the procedure below to install the ink cartridge.
1. Check the angle of the ink cartridge slot to see if the insertion angle of the ink cartridge is vertical.
• If the insertion angle of the ink cartridge is not vertical, change the angle.
3.4.5 Changing the angle of the ink cartridge slot
NOTE
Make sure that insertion of 440ml cartridge is from above the printer. If the cartridge is inserted
obliquely, the cartridge may fall over.
2. Turn the printer ON.
• The printer starts the initializing operation.
• After the initial operation is compete, "Start Ink Charge – > E" is displayed on the operation
panel.
No. Name
1 Ink cartridge slot
1
To Next Page
