5 Troubleshooting VJ-1624 QUICK REFERENCE
5-22
5.1.4.3 Custom Micro Adjustment Pattern
Check the confirmation pattern, and when the misalignment is small, perform micro adjustment.
This menu is made up with the following menus.
5.1.4.3.1 Adj. PatternALL
Print a Micro Adjustment Pattern ALL and register the setting value.
1. Display the Custom Adjust Print menu on the operation panel in the same way as in step 2 of "5.1.4.1
Custom Confirmation Pattern".
2. Press the [+] key or [-] key to select "Adj.3: Fine Ptn. ALL".
3. Press the [Enter] key on the operation panel.
• "Warming Up", and then "Warming Up Skip -> E" are displayed.
Menu Name Description Reference
Custom Micro
Adjustment
Pattern
Adj. PatternALL Adjust all confirmation patterns A to F.
5.1.4.3.1 Adj. PatternALL
Each Adjust
Patterns
Adjust all confirmation patterns A to F.
5.1.4.3.2 Each Adjust Patterns
To Next Page
