VJ-1624 QUICK REFERENCE 5 Troubleshooting
5-29
3. Move the print head section from the top of the media to the right.
NOTE
• When the head height is set to Low, switch it to High before moving the Head.
Change the setting back to Low after moving the Head.
"4.2.5.1 When raising the print head" in the Operation Manual
"4.2.5.2 When returning the print head to the original position" in the Operation Manual
4. Raise the media loading lever.
No. Name
1 Print head section
2 Roll media
No. Name
1 Media loading lever
2
1
1
To Next Page
