VJ-1638/1638W OPERATION MANUAL ERRATA
October 2012
VJ1638xE-A-01c 12 MUTOH INDUSTRIES LTD.
13. Press the [Enter] key.
"Wait for a while..." is displayed on the operation panel.
The printer checks the connection between the printer and spectrophotometer.
"Set white plate then close left maintenance cover." is displayed on the operation panel.
14. Remove the white reference plate from the plate installation place, turn it over so that the white
side faces up, and install it back to the original place
1
1
2
2
3
No. Name
1 White reference plate
2 Plate installation place
NOTE
Before measuring the color patches, make sure that the white side of the white reference plate is facing
up. If the black side is facing up, it will not be measured accurately.
To Next Page
