Maintenance
- 93 -
B
Error / malfunction messages
The dashboard can signal a fault or malfunction during
different motorcycle use conditions.
- Engine start-up: Turning the ignition switch to "ON",
the instrumentation and indicators run diagnostic
tests. When a vehicle fault is present, the display will
show an error message as shown in the figure to the
side. In particular, the motorcycle unit or component
where the malfunction was detected is highlighted.
- Press the "OK" button and the dashboard will pass
into "RUN" mode.
WARNING
Whenever the diagnostic tests detect a fault
with the vehicle stopped, do not start up the
machine and contact an authorised MV
Agusta service centre.
- Vehicle running: When a vehicle fault is detected
while running, an error message, shown to the side,
is shown on the lower part of the display.
WARNING
Whenever a fault is detected while the vehi-
cle is running, stop running and contact an
authorised MV Agusta service centre.
