MV Agusta F4 RR - Exhaust Tubes Removal

- 12 -
Frame
G
EXHAUST TUBE REMOVAL
NOTE: This operation is not necessary for disas-
sembly of the engine or frame. Proceed as descri-
bed below for exhaust manifold replacement.
Slide off the Lambda probe connector (1) and lift.
Remove the central protection by unscrewing the two
screws (2).
1
2
