- 34 -
Electrical system
E
The charge fuse is situated under the seat, in the posi-
tion indicated on the starter relay.
To accede to this component it is necessary to remove
the following parts:
• The driver’s seat;
• Remove the plastic covers on both fuses.
• Substitute the left fuse with the pare one as shown
in the figure.
• Fit a new 40A fuse in the spare fuse holder as soon
as possible.
SPARK PLUGS
Remove the components of the motorcycle to remove
the spark plugs as described in chapter B “Mainte-
nance”.
Recharge fuse
Spare fuse
Remove the spark plugs utilising the appropriate
16mm hexagonal spark plug spanner.
