- 20 -
Brakes
H
When reassembling, be careful to insert the
pin of the pump piston into the seat situated
on the lever (see figure).
Grease the pin:
Recommended grease: Agip Grease 30
For the reassembly of the lever tighten the pin.
Tighten the nut while holding the pin in place with a flat
blade screwdriver.
Torque pressure: 8 - 10 N·m
To remove the brake lever, follow the pro-
cedure used for the clutch lever.
8÷10 N•m
NOTE
CLUTCH/FRONT BRAKE LEVER REMOVAL (F4 RR)
Slacken the front brake lever pin, by keeping in place
the nut in the lower side.
