- 54 -
Maintenance
B
Maintenance
BRAKE PADS
Wear check / substitute
g At the first 1000 kilo-
metres and then every
6000 kilometres
Check the condition and thickness of the brake pads
on the calipers.
Measure the thickness of the pad linings. If the thick-
ness of the linings is equal to or less than the wear limit
shown below, replace the pads as described in chapter
H “Brakes”.
Wear limit: 1 mm
If the brake pads are substituted, it is nec-
essary to effectuate a proper running-in
period before reaching an optimal braking
efficiency.
Rear brake caliper
Front brake caliper
Disc
Pads
Wear limit 1 mm
Rotate the footrest support in the desired position.
Tighten the screw(1) at the prescribed torque pressure.
Footrest support screw torque pressure:
34 ÷ 38 N
.
m
Adjust both footrest to the same position.
1
34 ÷ 38 N•m
NOTE
