- 6-
Bodywork
C
Front fairing removal
With a small flat-tip screwdriver, remove the connector
(1) of the front headlight. Push the screwdriver forward
to unhook the connector.
Remove the two fixing screws (2) of the right rear-view
mirror.
Remove the connector and take off the right rear-view
mirror (3).
Repeat operations for the left mirror.
1
2
3
