Suspension and wheels
F
- 35 -
Disassembly of the steering sleeve
(F4 S - F4 FT - F4 RR)
By using the special tool, remove the steering sleeve
fixing screw ring.
Special tool No. 800092857
Attention: During this operation press the
centre of the tool with the palm of the hand.
Remove the adjustment screw (1) of the frame head
steering sleeve, sustaining the frame head steering
sleeve at the lower part.
Remove the sleeve (2).
1
2
Reassembly of the steering sleeve
(F4 S - F4 FT - F4 RR)
Clean the parts accurately so that a visual check can
be made of the tube and the seats.
There should not be marks or lines in the bearing
seats. If so, substitute the parts as necessary.
