MV Agusta F4 RR - Page 368

- 22 -
Frame
G
Remove the frame vacuum gauge sockets (4) on both
sides of the vehicle and recover with adhesive tape.
4
Loosen to end stroke the screws (5) of the two pairs of
clamps on the suction manifolds as shown in the figure.
5
Remove the complete throttle body unit.
