mycom 4032MSC

2201Q4JE-MY-C9-N_2018.01.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 4032**C Parts Configuration Table
7-11
No.
Part Name
Code No.
Remarks
Q’ty.
166-1
Hexagon Socket Head Cap Screw
NB35412-025
M12×25
4
166-2
Hexagon Socket Head Cap Screw
NB35405-010
M5×12
4
187-1
Snap Ring C type External
NG12-095
JIS B 2804 S95
1
187-2
Snap Ring C type External
NG12-095
JIS B 2804 S95
1
200-1
Unloader Indicator Fixture Assembly
CS20000-400
400V**
1
201
Bevel Gear (1)
CS20100-1612C9
1612LSC(Φ9)
1
202
Bevel Gear (2)
CS20100-1612C6
1612LSC(Φ6)
1
206
Glass Gland, Unloader Indicator
CS20600-1612
1612LSC
1
208
Shaft, Unloader Indicator
CS12200-400
400V**
1
208-A
Snap Ring C type External
NG12-010
S10
2
208-B
Bearing
CS16460-200
#6000LL
2
210
Cross-recessed and Pan Head Screw
NB35405-015
M5×15
4
212-A
Hexagon Socket Head Cap Screw
NB35405-030
M8×30
2
212-B
Hexagon Socket Head Cap Screw
NB35408-095
M8×95
2
212-C
Hexagon Socket Head Cap Screw
NB35408-020
M8×20
4
212-D
Spring Washer
ND320-008
M8
8
215-1a
Flange, Lubricating Oil Supply (1) to
Main Journal
CZA01-300C02B
ANSI #300 2"
1
215-1b
Flange, Lubricating Oil Supply (1) to
Side Journal
CZA01-300C01B
ANSI #300 1"
1
215-1c
Flange, Lubricating Oil Supply to TPTB
CZA01-300C02B
ANSI #300 2"
1
215-2
Flange, Lubrication Oil Supply (2) to
Journal
CZA01-300C02B
ANSI #300 2"
1
215-2
Flange, Lubricating Oil Supply (2) to
TPTB
CZA01-300C01B
ANSI #300 1"
1
216-1a
Flange Gasket, Lubricating Oil Supply
(1) to Main Journal
PL300-050
ANSI #300 2"
1
216-1b
Flange Gasket, Lubricating Oil Supply
(1) to Side Journal
PL300-025
ANSI #300 1"
1
216-1c
Flange Gasket, Lubricating Oil Supply to
TPTB
PL300-050
ANSI #300 2"
1
216-2
Flange Gasket, Lubrication Oil Supply
(2) to Journal
PL300-050
ANSI #300 2"
1
216-2
Flange Gasket, Lubricating Oil Supply
(2) to TPTB
PL300-025
ANSI #300 1"
1
217-1a
Stud Bolt
NBU605/8-11UNC
5/8 " -11UNC×75mm
8
217-1b
Stud Bolt
NBU605/8-11UNC
5/8 " -11UNC×75mm
4
217-1c
Stud Bolt
NBU605/8-11UNC
5/8 " -11UNC×75mm
8
217-2
Stud Bolt
NBU605/8-11UNC
5/8 " -11UNC×75mm
8
217-2
Stud Bolt
NBU605/8-11UNC
5/8 " -11UNC×75mm
4
-
Hexagonal Nut
NCU1505/8-11UNC
5/8 " -11UNC
32
218
Flange, Injection Oil Supply
CZA01-300C0204B
ANSI #300 2-1/2"
1
219
Flange Gasket, Injection Oil Supply
PL300-065
ANSI #300 2-1/2"
1
220
Stud Bolt
NBU603/4-10UNC
3/4" -10UNC×90mm
8
237-1
Torsional Slip Washer (1)
CS23700-400
400***
2
237-2
Torsional Slip Washer (2)
CS23700-320
320***
2
245
Special Spring Washer for Hexagon
Socket Head Cap Screw
ND330-14
No.3 14、400V**
8
246-1
Guide, Unloader Slide Valve
CS24600-400
400***
1
247-1
Hexagon Socket Head Cap Screw
NB35416-075
M16×75
8
250-1
Thrust Washer (1)
CS25000-400
400***
2
250-2
Thrust Washer (2)
CS25000-320
320***
2
267
Special Spring Washer for Hexagon
Socket Head Cap Screw
ND320-016
M16
4
