mycom 4032MSC User Manual

2201Q4JE-MY-C9-N_2018.01.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 4032**C Parts Configuration Table
7-12
No.
Part Name
Code No.
Remarks
Q’ty.
325
O-ring
PA11-070
JIS B 2401 P70
2
326-1
Gland, O-ring (1)
CS32600-400
400V**
1
326-2
Gland, O-ring (2)
CS32600-320
320***
1
328
O-ring
PA11-058
JIS B 2401 P58
1
346
Shaft Key for TPTB
CS34600-400
400***
2
419
Backup Ring
PBP21-070
SUN-2BP-70-T2
4
420
Spacer, Unload Position (30 % load)
CS42000-320S30
320S**
1(*SC)
420
Spacer, Unload Position (30 % load)
CS42000-320M30
320M**
1(*MC)
420
Spacer, Unload Position (30 % load)
CS42000-320L30
320L**
1(*LC)
420
Spacer, Unload Position (30 % load)
CS42000-320LL30
320LL*
1(*LLC)
421
O-ring
PA11-058
JIS B 2401 P58
2
432-1
O-ring
PA12-200
JIS B 2401 G200
4
432-2
O-ring
PA12-165
JIS B 2401 G165
4
433-1
O-ring
PA12-200
JIS B 2401 G200
4
433-2
O-ring
PA12-165
JIS B 2401 G165
4
594
Hexagon Socket Head Cap Screw
NB35420-075
M20×75
12
595-A
Hexagon Socket Head Cap Screw
NB35424-110
M24×110
10
595-B
Hexagon Socket Head Cap Screw
NB35420-110
M20×110
2
596
Alignment Pin
NE2316-065A
Φ16×65
2
597
Special Spring Washer for Hexagon
Socket Head Cap Screw
ND330-06
No.3 6
3
605-A
Plug
NF021-NPT03
NPT3/8
3
605-B
Plug
NF021-NPT010
NPT1 1/4
1
661
Snap Ring C type External
NG12-070
JIS B 2804 S70
1
674
O-ring for BOD type Mechanical Seal
PA62-039
AS568A 261
1
-
Flange, Oil drain
CZA01-300C0004B
ANSI #300 1/2"
1
-
Flange, Oil drain
CZA01-300C0004B
ANSI #300 1/2"
1
-
Flange, Oil drain
CZA01-300C01B
ANSI #300 1"
1
Flange Gasket, Oil drain
CZA01-300C0004B
ANSI #300 1/2"
1
Flange Gasket, Oil drain
CZA01-300C0004B
ANSI #300 1/2"
1
Flange Gasket, Oil drain
CZA01-300C01B
ANSI #300 1"
1
Stud Bolt
CZA01-300C0004B
1/2" -13UNC×60mm
4
Stud Bolt
CZA01-300C0004B
1/2" -13UNC×60mm
4
Stud Bolt
NBU605/8-11UNC
5/8" -11UNC×75mm
4
Hexagonal Nut
NCU1501/2-13UNC
1/2" -13UNC
8
Hexagonal Nut
NCU1505/8-11UNC
5/8" -11UNC
4
 The part code of the O-ring is the one assigned to NBR which is standard material.
When the material of the O-ring is other than NBR, a different part code is used for
each material.
If you are using O-rings made from other than the standard material, please contact
MAYEKAWA when placing an order.
