mycom 4032MSC

2201Q4JE-MY-C9-N_2018.01.
Chapter 5 Maintenance and Inspection
Compound 2-stage Screw Compressor 4032**C 5.3 Compressor Disassembly Preparation
5-8
P/N
Part Name
Code No.
Remarks
Q’ty.
9
O-ring JIS B 2401 G95
PA12-095
1
12-1
Gasket, Bearing Head (1)
CS01200-400
1
12-2
Gasket, Bearing Head (2)
CS01200-320N
1
17-1
Gasket, Bearing Cover (1)
CS01700-400
1
17-2
Gasket, Bearing Cover (2)
CS01700-4032CN
1
23
Gasket, Balance Piston Cover
CS02300-320N
1
27-1
Main Bearing (1) with O-ring (No.432-1)
CS0270-4032N
2
27-2
Main Bearing (2) with O-ring (No.432-2)
CS0270-GRT
2
28-1
Side Bearing (1) with O-ring (No.433-1)
CS02800-4032N
2
28-2
Side Bearing (2) with O-ring (No.433-2)
CS0280-GRT
2
30
Balance Piston
CS03000-320
To be replaced if any
abnormality is found.
1
33
Balance Piston Sleeve
CS03300-320
1
35
O-ring JIS B 2401 G190
PA12-190
1
38-1A
Thrust Bearing (1) A TPTB (DAIDO)
CS03800-T400M
1
38-1B
Thrust Bearing (1) B TPTB (DAIDO)
CS03800-T400F
1
38-2
Thrust Bearing (2)
320** A-angle Cast retainer
CS03800-320
2
38-2
Thrust Bearing (2) 320*** TPTB
CS03800-T00320
-
39-1
Lock Nut (1) AN28
NG31-028
To be replaced if any
abnormality is found.
2
39-2
Lock Nut (2) AN21
NG31-021
2
40-1
Lock Washer (1) AW28X
NG32-028x
2
40-2
Lock Washer (2) AW21
NG32-021
2
63-1
O-ring JIS B 2401 G250
PA12-250
1
63-2
O-ring JIS B 2401 G240
PA12-240
1
65-1
O-ring JIS B 2401 P215
PA11-215
1
65-2
O-ring JIS B 2401 P200
PA11-200
1
66-1
Cap Seal (1) BE-215
CS06600-400
1
66-2
Cap Seal (2) BE-200
CS06600-320
1
68-1
Guide Pin (1)
NE2506-016
To be replaced if any
abnormality is found.
1
68-2
Guide Pin (2)
NE2506-016
1
69-1
Lock Nut (1) AN10, Unloader Piston (1)
NG31-010
To be replaced if any
abnormality is found.
2
69-2
Lock Nut (2) AN10, Unloader Piston (2)
NG31-010
1
70-1
Lock Washer (1), Unloader Piston (1) AW10
NG32-010
1
70-2
Lock Washer (2), Unloader Piston (2) AW10
NG32-010
1
73-1
O-ring JIS B 2401 G45
PA12-045
1
73-2
O-ring JIS B 2401 P44
PA11-044
1
75-1
O-ring JIS B 2401 G220
PA12-220
1
75-2
O-ring JIS B 2401 G210
PA12-210
1
78-1
Ball Bearing, Indicator Cam (1) #6302
CS07800-400
1
78-2
Ball Bearing, Indicator Cam (2) #6000
CS07800-200
1
79-1
Snap ring C type External S15
NG12-015
To be replaced if any
abnormality is found.
1
79-2
Snap ring C type External S10
NG12-010
1
82-1
V-ring, Indicator Cam VH10 NBR
CS08200-200B
1
82-2
V-ring, Indicator Cam VH10 NBR
CS08200-200B
1
89-2
O-ring JIS B 2401 P24
PA11-024
2
93-1
Gasket, Suction Flange (1)
PL300-400
ANSI #300 16"
1
