mycom 4032MSC

2201Q4JE-MY-C9-N_2018.01.
Chapter 5 Maintenance and Inspection
Compound 2-stage Screw Compressor 4032**C 5.3 Compressor Disassembly Preparation
5-9
P/N
Part Name
Code No.
Remarks
Q’ty.
93-2
Gasket, Suction Flange (2)
PL300-300
ANSI #300 12"
1
96-1
Gasket, Discharge Flange (1)
PL300-300
ANSI #300 12"
1
96-2
Gasket, Discharge Flange (2)
PL300-200
ANSI #300 8"
1
100
Mechanical Seal Assembly 400*** BBD-E
CS1002-400EBD
1
125
Micro Switch
CS12500-200
To be replaced if any
abnormality is found.
4
129
Potentiometer 200-1 k, with lead wire
CS1299-E10
1
150-1
O-ring JIS B 2401 G290
PA12-290
2
150-2
O-ring JIS B 2401 G220
PA12-220
2
-
Gear Coupling Assembly (Current Type)
-
To be replaced if any
abnormality is found.
1
159
Knurled Cup Point Socket Set Screw
NA83610-016
2
163
O-ring JIS B 2401 G65
PA12-065
1
201
Bevel Gear (1), Low-stage Indicator Casting
CS20100-1612C9
To be replaced if any
abnormality is found.
1
202
Bevel Gear (2), Low-stage Indicator Casting
CS20100-1612C6
1
208-A
Snap Ring S10, Same above
NG12-010
To be replaced if any
abnormality is found.
2
208-B
Ball Bearing #6000LL, Same above
CS16460-200
2
216-1a
Gasket, Lubricating Oil Inlet Flange(1) Main
PL300-050
ANSI #300 2"
1
216-1b
Gasket, Lubricating Oil Inlet Flange(1) Side
PL300-025
ANSI #300 1"
1
216-1c
Gasket, Lubricating Oil Inlet Flange TPTB
PL300-050
ANSI #300 2"
1
216-2
Gasket, Lubricating Oil Inlet Flange Journal
PL300-050
ANSI #300 2"
1
216-2
Gasket, Lubricating Oil Inlet Flange TPTB
PL300-025
ANSI #300 1"
1
219
Gasket, Oil Injection Inlet Flange
PL300-065
ANSI #300 2-1/2"
1
237-1
Tortional Slip Washer (1)
CS23700-400
2
237-2
Tortional Slip Washer (2)
CS23700-320
2
325
O-ring JIS B 2401 P70
PA11-070
2
328
O-ring JIS B 2401 P58
PA11-058
1
421
O-ring JIS B 2401 P58
PA11-058
2
432-1
O-ring JIS B 2401 G200
PA12-200
4
432-2
O-ring JIS B 2401 G165
PA12-165
4
433-1
O-ring JIS B 2401 G200
PA12-200
4
433-2
O-ring JIS B 2401 G165
PA12-165
4
674
O-ring, BOD type Mechanical Seal
PA62-039
AS568A -261
1
In case of replacing the main/side bearings of No.27 and No.28, it is not necessary to prepare the
O-rings of No.432 and No.433 because the main/side bearings have the O-rings.
● The part code of the O-ring is the one assigned to NBR which is standard material.
When the material of the O-ring is other than NBR, a different part code is used for
each material.
If you are using O-rings made from other than the standard material, please contact
us when placing an order.
