EV-030 Rev. 07 – 2008
English
36
Measurement menu
Measure
Reset Measure No
Units Feet
Rope_Chain Off
Exit
Use the (DOWN) or (UP) key to move around the parameters.
Reset Measurement
Resets the chain measurement value
(0.0).
Select with
= Yes = No
Confirm with
Units
Selects the unit of measurement:
Feet/ inches
Metres / centimetres
Select with
= Feet = Metres
Confirm with
Rope_Chain
It is possible to enable the function and
set the value at which the sensor
passes from rope to chain. Setting
range 0.1 - 25.0 (metres or feet). This
value corresponds to the chain length.
To obtain this function, install
sensor CMCT-01 (optional).
Select with
Set value with
Confirm with
Exit
To return to the settings menu.
Confirm with
To Next Page
