Nabco Acusensor M User Manual

9 of 28
www.NabcoEntrances.com AcusensorMInstallaonManual
Rev 8-25-17 P/N C-00187
DN 1580
Figure 3 Install the Angled Sensor


DN 1578
7
6
54
321
10
98
11 12 13 14
ACUSENSOR M TO OPUS IN SWING DOOR WITH MONITORING
ACUSENSOR M
ACUSENSOR M
APROACH SIDE (ACTIVATION)
SWING SIDE (SAFETY)
RED
BLACK
BROWN
GREEN
V-00741
V-00741
ACUSENSOR M HARNESS
A-01292
ACUSENSOR M HARNESS
A-01292
YELLOW
GREY
RED
BLACK
BROWN
GREEN
YELLOW
GREY
P.N. A-00805
ON/OFF/HOLD-OPEN SWITCH
BLUE
WHITE
BLACK
RED
Off
Hold Open
On
Off
