Nabco U30 - Page 22

Rev. 3-12-13 Part #15-9000-30
www.NabcoEntrances.com U30 Microprocessor Control
5-23 Adjustment Procedures
Extra Funcon Adjustments
Adjustment Descripon
connued.... Two 4 inch prior to the full open posion.
Back-check Posion Three 5 inch prior to the full open posion.
Latch-check Posion Message will read FUNCTION(12) 0
● Determines where latch-check starts in the closing cycle.
● The following (4) opons are available:
Zero 2 inch prior to the full open posion.
One 3 inch prior to the full open posion.
Two 4 inch prior to the full open posion.
Three 5 inch prior to the full open posion.
Programs the Funcons
of Signal Input for: Green/
White SLS on Terminal 11
Message will read FUNCTION(13) 1
● Programs Input Terminal # 11 to receive signals from various devices.
● The following Sengs (0 - 3) are available:
Sengs =
1 or 0
Sidelite Sensor
Indicates to the U30 Microprocessor Control that a Sidelite Sensor is present.
Please refer to the Sidelite Sensor Seng chart (opon 1 or 0) that denes
the Slide door behavior, shown below:
Funcon Seng Door Posion Door reacon when Sidelite
Sensor is Acvated
Opon set to “0” Fully Closed Door stays closed
Opening Door connues opening
Opon set to “1” Fully Closed Door opens slowly
Opening Door opens slowly
Sengs = 2
(Used for
emergency
purposes
only)
Emergency Close and Lock
● Instructs the U30 Microprocessor Control to immediately close and lock
the Slide door (if lock equipped). In that event:
● The Slide door will close at normal speed provided an acvaon signal is
not present on Wires 61, 62 or 6B.
● If an acvaon signal is present on Wires 61, 62 or 6B, the Slide door
will close at creep speed.
● Once the acvaon signal is removed from Terminal 11, the Slide door will
resume normal operaon.
● If the Slide door is already fully closed, it will stay closed.
Sengs = 3 All Mode Acvaon
Instructs the U30 Microprocessor Control to open the Slide door in any
Rocker Switch posion except OFF.
The U30 Microprocessor Control will ignore One Way, Two Way, or Night
mode sengs on the Rocker Switch and open the Slide door.
