Adjustment Procedures 5-24
U30 Microprocessor Control www.NabcoEntrances.com
Part #15-9000-30 Rev. 3-12-13
Extra Funcon Adjustments
Adjustment Descripon
Output Timer 2 Message will read FUNCTION(14) 0
● Output Timer 2 selecon is required only when selecng Opon 2 on the “Auxiliary
Output 2” adjustment.
● The following (4) opons are available:
Zero 2 seconds
One 4 seconds
Two 6 seconds
Three 8 seconds
Incremental
Open Speed Adjustment
Message will read FUNCTION (21) 0
● Ranges are 0 - 7 (Seng 0 has no eect).
● Allows Open speed to be set in between the Standard Open Speed sengs found in
Standard Funcon Adjustments.
Example Given:
Aer seng up the Slide door, it was found that Open Speed Seng (3) was too slow
and open Speed Seng (4) was too fast. It was possible to achieve an open speed seng
halfway between 3 and 4 by seng the Incremental open speed FUNCTION (21) to seng
4. Thus allowing the Slide door to open at a speed that was approximately equal to 3.5.
Incremental Close Speed
Adjustment
Message will read FUNCTION(22) 0
● Ranges are 0 - 7 (Seng 0 has no eect).
● Allows Open speed to be set in between the Standard Open Speed sengs found in
Standard Funcon Adjustments.
Example Given:
Aer seng up the Slide door, it was found that Open Speed Seng (3) was too slow
and open Speed Seng (4) was too fast. It was possible to achieve an open speed seng
halfway between 3 and 4 by seng the Incremental open speed FUNCTION (21) to seng
4. Thus allowing the Slide door to open at a speed that was approximately equal to 3.5.
Incremental Close Speed
Adjustment
Message will read FUNCTION(22) 0
● Ranges are 0 - 7 (Seng 0 has no eect).
● Allows close speed to be set in between the Standard Close Speed sengs found in
Standard Funcon Adjustments.
Auxiliary Output 2 Message will read FUNCTION(23) 3
● Determines when the internal transistor connected to OUT on Terminal 15 (BRN/YEL)
and 7 on Terminal 16 (RED) turns on for the operaon of another controller, relay or other
device.
The following (7) opons are available:
Zero Signal at Full Open Transistor will turn ON at the full open posion.
One Air Lock Opon In a passageway situaon, Opon (1) instructs the
Transistor to turn ON to prevent a second Slide door
from opening before the rst Slide door reaches the
fully closed posion.
