NAD C 730 - Page 23

25
C833 150F-223Z-5-UG CC 50V 0.022µF +80/-20%
C840-C843 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C844 153F-103J-5-IM CM 50V 0.01µF 5% RL 5x7
C845 157B-107M-5-KMK CE 6.3V 100µF 20% RL
C846 150F-223Z-5-UG CC 50V 0.022µF +80/-20%
C847, C848 157D-476M-5-IMK CE 16V 47µF 20% RL
C849-C852 157D-106M-5-IUK CE 16V 10µF 20% RL 5x11
C853 157D-337M-5-OVK CE 16V 330µF 20% RL
C864 153F-103J-5-IM CM 50V 0.01µF 5% RL 5x7
C865 157D-106M-5-GMN CE 16V 10µF 20% RL 4x7
C913, C914 157D-106M-5-IUK CE 16V 10µF 20% RL 5x11
DIODES
D305-D309 4804-1480-C DIODE 1N4148 ATS
D501, D502 4840-2040-0 BRIDGE RECTIFIER RS403L
D503 4804-1480-C DIODE 1N4148 ATS
D601 4837-27D1-2 DZ 1/2W 26.29~27.64V
D602-D605 4804-0040-2 DIODE 1N4004 AT
D607-D609 4804-0040-2 DIODE 1N4004 AT
D801, D802 4804-0040-2 DIODE 1N4004 AT
D803-D807 4804-1480-C DIODE 1N4148 ATS
D808, D809 4837-18V6-2 DZ 1/2W 18V TEMIC AT
D810-D812 4804-1480-C DIODE 1N4148 ATS
D815 4837-12V6-2 DZ 1/2W 12V 5% TEMIC AT
D816-D820 4804-1480-C DIODE 1N4148 ATS
D910 4804-0040-2 DIODE 1N4004 AT
J709, J729 4837-3A31-2 DZ 1/2W 3.16~3.38V ROHM
COILS
L801, L802 1804-0540-0 SPRING COIL 1MH
L804 1803-0014-0 COIL 1µH 10% BL 7
JACKS
M503 2113-1179-0 PHONE JACK D3.5 BK
J504 2113-1121-0 2P RCA JACK Y/Y AU
R883, R884, M701 2113-1818-0 6P RCA JACK W/R GOLD
RELAY
M801 4500-0910-0 RELAY 24VDC,125VA,3A
TRANSISTORS
M501, M502 4860-5270-5 TR TYN412 400V 12A
Q501 4860-0660-5 TR 2SA1015 (G.R.) RL
Q502 4860-0700-5 TR 2SC1815 (G.R) RL
Q503 4860-0660-5 TR 2SA1015 (G.R.) RL
Q504 4860-0700-5 TR 2SC1815 (G.R) RL
Q505, C506 4860-0660-5 TR 2SA1015 (G.R.) RL
Q601 4860-0660-5 TR 2SA1015 (G.R.) RL
Q701, Q702 4851-241A-5 TR RN1241-A
Q801 4860-0700-5 TR 2SC1815 (G.R) RL
Q802-Q804 4860-0190-5 TR 2SC 1845 (F.E) RL
Q805 4860-0700-5 TR 2SC1815 (G.R) RL
Q806 4860-0190-5 TR 2SC 1845 (F.E) RL
Q807, Q808 4860-1590-5 TR 2SC1740S
Q809-Q812 485A-949O-5 TR 2SA949-O HFE 70-140
Q813, Q814 485D-667A-5 TR 2SD667A HFE 100-200
Q815, Q816 485A-949O-5 TR 2SA949-O HFE 70-140
Q817-Q822 485C-2229-5 TR 2SC2229-0 HFE 70-140
Q823, Q824 485B-647A-5 TR 2SB647A-C HFE 100-200
Q825, Q826 485C-5196-5 TR 2SC5196-0
Reference No. Part No. Description
