NAD C 730 - Electrical Parts List

24
ELECTRICAL PARTS LIST
Reference No. Part No. Description
LED ASSEMBLY
PCB BOARD
01000 PCB-N0940C-LED LED ASSEMBLY
LED
D211 3700-3517-RG LED RED/GREEN (L-469HGW)
MAIN ASSEMBLY
PCB BOARD
02000 PCB-N0940C-MAIN MAIN ASSEMBLY
CAPACITORS
C330, C332 150F-104K-2-FC CC 50V 0.1µF 10% AT
C333 150F-223K-2-FD CC 50V 0.022µF 10% AT
C401-C418 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C420 153F-103J-5-IM CM 50V 0.01µF 5% RL 5x7
C501, C502 8910-0057-0 CE 63V 4700µF 20% RL
C503, C504 157F-106M-5-IMK CE 50V 10µF 20% RL 5x7
C505 153F-104J-5-QUN CM 50V 0.1µF RL (9x11)
C506, C507 157D-106M-5-IUK CE 16V 10µF 20% RL 5x11
C601, C602 157F-106M-5-IMK CE 50V 10µF 20% RL 5x7
C603, C604 150F-223K-2-FD CC 50V 0.022µF 10% AT
C605 157E-338M-5-5$ CE 25V 3300µF 20% RL
C606 157E-108M-5-X& CE 25V 1000µF 20% RL
C607 157B-227M-5-LMK CE 6.3V 220µF 20% RL
C608-C610 150F-223K-2-FD CC 50V 0.022µF 10% AT
C611 157F-107M-5-OW CE 50V 100µF 20% RL 8x12
C613 157F-476M-5-LU CE 50V 47µF 20% RL
C747 157D-106M-5-IUK CE 16V 10µF 20% RL 5x 11
C748 150F-330J-2-FC CC 50V 33PF 5% AT 3.5x 2
C761, C762 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C763, C764 157C-476M-5-IMK CE 10V 47µF 20% RL 5x7
C765-C770 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C771, C772 157D-106M-5-IUK CE 16V 10µF 20% RL 5x11
C773, C774 153F-103J-5-IM CM 50V 0.01µF 5% RL 5x7
C775, C776 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C777, C778 153F-183J-5-KP CM 50V 0.018µF 5% RL
C779, C780 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C781, C782 157D-106M-5-IUK CE 16V 10µF 20% RL 5x11
C783, C784 157F-105M-5-GMK CE 50V 1µF 20% RL 4x7
C785, C786 150F-221K-5-GG CC 50V 220pF 10% RL 4x4
C787, C788 157C-107M-5-IU CE 10V 100µF 20% RL 5x11
C789 157D-106M-5-GMN CE 16V 10µF 20% RL 4x7
C801, C802 157E-226M-5-GMK CE 25V 22µF 20% RL 4x7
C803, C804 150F-151K-2-FC CC 50V 150pF 10% AT 3.5x
C805, C806 15CH-020C-5-GG CTC 0/60 2pF 0.25pF RL
C807, C808 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C809, C810 157D-107M-5-KUK CE 16V 100µF 20% RL
C811, C812 157D-476M-5-IMK CE 16V 47µF 20% RL
C813, C814 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C815, C816 150F-070D-5-GG CC 50V 7PF 0.5PF RL 4x4
C817-C820 157F-106M-5-IMK CE 50V 10µF 20% RL 5x7
C821, C822 150F-223Z-5-UG CC 50V 0.022µF +80/-20%
C823, C824 153F-473J-5-NLM CM 50V 0.047µF 5% RL 7.5
C829, C830 157F-108M-5-X& CE 50V 1000µF 20% RL
