NAD C 730 - Exploded View Parts List

35
ITEM Part No. Description Qty
0101 *AH 1403-7071-0 REAR PANEL C730 (AH) 1
0101 *C 1403-7072-0 REAR PANEL C730 (C) 1
0102 1403-7080-0 TOP COVER C730 1
0103 1403-7090-0 SUB-FASCIA C730 1
0104 1403-7100-0 BOTTOM COVER C730 1
0105 1403-7110-0 BOTTOM CHASSIS C730 1
0106 1466-8200-0 FASCIA C730 1
0107 4154-2091-0 INPUT BUTTON LOZENGE C730 1
0108 3716-4315-0 WINDOW LENS C730 W/SS 1
0109 2444-1301-1 BUTTON RACKER 1
0110 4154-0091-0 BEZEL RACKER 1
0111 2444-2101-0 INPUT BUTTON 3
0112 2444-1201-0 BUTTON TRIO 2
0113 4154-0031-0 BEZEL TRIO 3
0114 4152-4631-0 RUBBER FOOT (522) 14MM HIGH 4
0115 4152-4641-0 CUSHION FOOT (522) 4
0116 4152-4331-0 POWER BUTTON BEZEL 1
0117 3714-5706-0 LED LENS (412) CLEAR SAN 1
0118 4152-3851-0 SQ. STRAIN RELIEF BUSHING 1
0119 *AH 7009-3100-2 AC CORD 18AWGX2 1
0119 *C 7009-3100-0 AC CORD (SEMKO) 1
0120 4152-0451-0 L-BRACKET 1
0121 2442-1000-0 POWER BUTTON 1
0122 2445-0201-0 TONE KNOB SHORT C730 3
0123 2445-0301-0 TONE DEFEAT BUTTON 1
0124 2445-0401-0 VOLUME KNOB SHORT C730 1
0125 5400-9171-0 FRONT HEATSINK C730 1
0126 5400-9181-0 REAR HEATSINK C730 1
0127 2600-4008-0973 FLAT WASHER M4X0.8X9.7 BZ 4
0128 2607-4010-0703 SPRING WASHER M4X1X7 BZ 4
0129 2904-4010-3000 SCREW M4X10 (BLK) 4
0130 2954-3008-3000 T3X8MM SELF TAPPING 42
0131 2842-3367-0 METAL WASHER ID=3.3 OD=6.7 4
0132 2900-4006-3010 M4X0.5PX6MM W/FLAT WASHER 4
0134 2954-3006-0000 3X6MM B-TITE (YEL.ZN) 1
0135 2954-3008-0000 TAPPING 3X8MM B-TITE (YEL.ZN) 8
0136 2954-3006-3000 3X6MM B-TITE (BLK.ZN) 8
0140 2954-2606-3000 SCREW BH 2.6X6 BLACK 11
0142 2954-2608-3000 SCREW BT 2.6X8 BLACK ZINC 11
0145 2904-3006-0000 SCREW M3X6 4
0146 2904-3008-0000 M3X8MM BINDING HEAD (YEL.ZN) 1
0149 2640-4030-0703 M4 NUT (BLK) 4
0152 4154-2191-0 TONE CONTROL LOZENGE, N0940C 1
0155 2900-3010-3030 SCREW M3X10 W/S&F WASHER (BLK) 4
0158 5400-0831-0 HEATSINK (214) 20MM-HIGH HOLE 4
0161 2601-3004-0801 FIBRE WASHER M3X0.4X8 NA. 7
0162 2640-C020-1434 HEXAGON NUT M12X2.0X14.3 NI 1
EXPLODED VIEW PARTS LIST
