NAD c390dd - Page 15

∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
00-39000-00 C390DD
01-39001-00 MAIN BOARD
02-39001-00 SMT
PCB
A16-39001-21 C390DD MAIN PCB
IC
03-00165-01 8-Bit Serial or Parallel-Input/ Serial-Output Shift Register HC165 U1003
03-02021-01 POWER-DISTRIBUTION SWITCHES TPS2021D U1038
03-00244-07
LOW VOLTAGE CMOS OCTAL BUS BUFFER (3-STATE) WITH 5V
TOLERANT INPUTS AND OUTPUTS
SN74AHC244PW U1020
03-00714-01 TinyLogic. UHS Dual Inverter with Schmitt Trigger Inputs NC7WZ14P6X U1022
03-03357-01
SINGLE 5-W SP3T ANALOG SWITCH 5-V/3.3-V 3:1 ANALOG
MULTIPLEXER/DEMULTIPLEXER
TS5A3357DCU U1025, U1031
03-03253-03 DUAL 1 OF 4 FET MULTIPLEXER/ DEMULTIPLEXER SN74CB3Q3253PWR U1005, U1012
03-00595-01 Shift Register SN74HC595DR/ 74HC595D,118/ MM74HC595MX U1009
or 03-00595-06 8 BIT SHIFT REGISTER SN74HC595PW U1009
03-00541-07 Octal Buffer SN74AHC541DBR U1010, U1021, U1030
03-03125-01
QUADRUPLE FET BUS SWITCH 2.5-V/3.3-V LOW-VOLTAGE
HIGH-BANDWIDTH BUS SWITCH
74CB3Q3125PW U1013
03-01117-06 Linear Regulator(3.3v) AMS1117-3.3 U1014, U1026
03-00331-01 High-Speed USB 2.0 (480-Mbps) 1-Port Switch With Single Enable TS3USB31RSER U1015, U1023, U1036
03-00125-03 3-STATE Quad buffer
74VHC125MTC/74VHC125MTCX
/SN74LVC125APWR
U1016
03-02464-02 BUS EEPROM 24LC64-I/SN U1018
03-00734-01 TinyLogic UHS Triple Buffer NC7NZ34 U1001, U1004, U1008, U1017, U1024
03-00716-01
TinyLogic UHS Dual Buffer(TinyLogic 䍙催䗳ঠ㓧ކ఼)
NC7WZ16
U1000, U1002, U1006, U1007, U1011, U1019,
U1028
03-54331-01
3A 28V INPUT STEP DOWN SWIFT™ DC/DC CONVERTER WITH
Eco-mode
TPS54331D
U1035
03-03825-33 Processor Supervisory Circuits TPS3825-33DBVT U1033
03-00717-01 TinyLogic UHS Dual Buffer with Schmitt Trigger NC7WZ17 U1032, U1034
03-00221-02
High-Speed USB 2.0 (480 Mbps) 1:2 Multiplexer/Demultiplexer
Switch With Single Enable
TS3USB221ARSER U1029
03-32460-02 PIC32 MCUs (Microcontrollers) 512KB PIC32MX460F512L-80I/PT U1027
33-20012-01 SCHOTTKY DIODE SMD SS12 SMA D1002
33-20336-01 SCHOTTKY DIODE SMD SS36, SCHOTTKY,60V D1004
