C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
33-40352-01 Switch Diode 1SS352(TPH3,F),1SS355TE-17
D6201, D6202, D6203, D6204, D6205, D6206,
D6210, D6212
33-13609-10 Zener Diode 3.6V, 0.5W LL34 D1003
33-14709-10 Zener Diode 4V7,1/2W, LL34 D1000,D1001, D1005, D1006
Transistor
31-00114-01 Digital transistors (built-in resistors) DTA114EKA Q1013
31-00114-05 Digital Transistor(Built in Resistor) DTC114EKA
Q1003, Q1004, Q1007, Q1008, Q1011,
Q1014,Q1000, Q1012
31-02301-01 P-Channel Enhancement Mode MOSFET APM2301 Q1001, Q1002, Q1005, Q1006, Q1009, Q1010
Crystal
04-22452-02 Crystal
HLX-O-3-6-24.576M-1020-1060-1,24.576MHz
10ppm
U1037
04-18001-01 Crystal
8.000MHZ,HC-49/SMD8.0000MHz 18pF/ECS-80-
18-5PX-TR
Y1000
Inductor
08-04609-01 Ferrite Bead SMD BEAD,600 OHM@100MHZ,0.5A,0805 L1002, L1003
08-04100-08 chip inductor 10uH L1000
08-05100-01 chip inductor 10uH L1001
Capacitor
26-20051-00 Ceramic Chip Capacitor 20pF,50V,±5%,NP0,0603 C1046, C1053
26-27051-00 Ceramic Chip Capacitor 27PF,50V,±5%,NP0,0603 C1084
26-33151-10 Ceramic Chip Capacitor 330PF,50V,±5%,X7R,0603 C1006, C1020, C1023, C1025, C1030
26-39151-00 Ceramic Chip Capacitor 390PF,50V,±5%,NP0,0603 C1062
26-10251-10 Ceramic Chip Capacitor 1nJ,50V,0603,NPO C1063, C1065, C1066
26-22251-00 Ceramic Chip Capacitor 2.2nF,50v,±5%,NP0,0603 C1054
26-10351-00 Ceramic Chip Capacitor 10nK,50V,0603,X7R C1039, C1040, C1163, C1164
26-15321-00 Ceramic Chip Capacitor 15nK,25V,0603,X7R C1073
26-10411-00 Ceramic Chip Capacitor 100nF,16V 0603, X7R,±10%
C1000, C1001, C1002, C1003, C1004, C1005,
C1007, C1008, C1009, C1010, C1012, C1013,
C1015, C1019, C1021, C1022, C1024, C1027,
C1028, C1029, C1032, C1033, C1034, C1035,
C1036, C1037, C1038, C1041, C1042, C1043,
C1047, C1049, C1052, C1055, C1056, C1059,
C1060, C1069, C1071, C1074, C1159, C1160,
C1161, C1162
26-10660-00 Ceramic Chip Capacitor 10uF,0603,6.3V,X5R,±5% C1011, C1014
26-10611-01 Ceramic Chip Capacitor 10uF,10V,0805,X5R,±5% C1016, C1171, C1141, C1119, C1155
26-22351-01 Ceramic Chip Capacitor 22nK,50V,0805,X7R C1077, C1078, C1079, C1081, C1082
26-10451-11 Ceramic Chip Capacitor 100nK,50V,0805,X7R,±10% C1058
26-10451-01 Ceramic Chip Capacitor 100nZ,50V,0805,Y5V C1061
26-22521-01 Ceramic Chip Capacitor 2.2uF,±10%,25V,X5R,0805 C1068
26-22660-11 Ceramic Chip Capacitor 22U,6.3V,±10%,X5R, 0805
C1017, C1018, C1026, C1031, C1050, C1057,
C1064, C1072
Resistor
07-90000-00 Chip Resistor 0R
R1000, R1001, R1002, R1005, R1012, R1013,
R1052, R1055, R1057, R1058, R1081
07-91009-00 Chip Resistor 10,0603,1/10W,±1% R1091
