C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
07-90330-00 Chip Resistor 33,0603,1/10W,±5%,RC0603JR-0733RL R1121
07-93909-00 Chip Resistor 39,0603,1/10W,±1%,RC0603FR-0739RL R1108, R1109
07-91000-00 Chip Resistor 100,0603,1/10W,±1%
R1003, R1004, R1006, R1008, R1010, R1011,
R1014, R1015, R1016, R1017, R1019, R1020,
R1022, R1024, R1026, R1034, R1035, R1036,
R1037, R1038, R1039, R1040, R1046, R1048,
R1049, R1066, R1071, R1076, R1077, R1079,
R1080, R1083, R1088, R1089, R1110
07-90121-00 Chip Resistor 120,0603,1/10W,±5%
R1043ˈR1062
07-91001-00 Chip Resistor 1K,0603,1/10W,±1% R1041, R1042
07-94701-00 Chip Resistor 4.7K,0603,1/10W,±1% R1087
07-90103-00 Chip Resistor 10K,0603,1/10W,±5%,RC0603JR-0710KL
R1007, R1018, R1029, R1030, R1031, R1032,
R1033, R1047, R1051, R1053, R1056, R1061,
R1063, R1068, R1069, R1072, R1073, R1074,
R1075, R1093, R1095, R1096, R1099, R1100,
R1101, R1122, R1189
07-90273-00 Chip Resistor 27K,0603,1/10W,±5% R1086
07-90473-00 Chip Resistor 47K,0603,1/10W,±5%, R1119, R1120
07-91003-00 Chip Resistor 100K,0603,1/10W,±1% R1067, R1070
07-90105-00 Chip Resistor 1M,0603,±5%,1/10W R1085
07
-
90100
-
01
Chip Resistor
10 0805 1/8W ±5%
R1028
07
-
90100
-
01
Chip
Resistor
10
,
0805
,
1/8W
,
±5%
R1028
07-91000-01 Chip Resistor 100,0805,1/8W,±1% R1111, R1112, R1114, R1115
07-91621-01 Chip Resistor 1.62K,0805,1/8W,±1% R1107
07-99091-01 Chip Resistor 9.09K,0805,1/8W,±1%,RC0805FR-079K09L R1105
07-95362-01 Chip Resistor 53.6K,0805,1/8W,±1% R1118
07-91153-01 Chip Resistor 115K,0805,1/8W,±1% R1117
07-93323-01 Chip Resistor 332K,0805,1/8W,±1% R1106
07-90470-10 R Networks 47R,0603X4,1/10W,±5% R1102
07-90121-10 R Networks 120R,0603X4,1/10W,±1%
R1021, R1023, R1025, R1027, R1044, R1045,
R1050, R1054, R1059, R1060, R1064, R1065,
R1090, R1092, R1094, R1097
07-90103-10 R Networks 10k,0603X4,1/10W,±5% R1009
CAPACTIOR
06-33121-09 Alu Electrolytic Capacitor CD284,330uF,25V,±20%,F5.0,D=8 C1067
06-22111-32 Alu Electrolytic Capacitor CD284,220uF,10V,±20%,F2.5,D6.3 C1085
06-47111-12 Alu Electrolytic Capacitor CD263,470uF,16V,±20%,F5.0 C1051
06-33160-01 Alu Electrolytic Capacitor HCN,330uF,6.3V,±20%,F3.5 C1070, C1076
06-33160-08 Alu Electrolytic Capacitor CD284,330uF,6.3V,±20%,F3.5 C1075
01-39003-00 FPP BOARD
PCB
A16-39003-21
C390DD FPPǂPCB
IC
03-01117-01 Linear Regulator LM1117MPX-5.0/AMS1117-5.0 U3007
03-00734-01 Buffer NC7NZ34K8X U3006
03-00125-06 Buffer SN74AHC1G125DCK U3004
03-00165-01 Shift Register SN74HC165D/MM74HC165M/74HC165D U3008
03-00244-08 Octal Buffer SN74HCT244PWR U3003, U3005
03-01826-21 MCU
PIC18F26K20-I/SS(⚻C390DD⿟ᑣ)
U3002
03-01826-01 MCU PIC18F26K20-I/SS,SSOP-28 U3002
03-02985-33 Ragulator LP2985-33DBVR U3010
