NAD c390dd - Page 24

∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
07-94708-00 Chip Resistor 4.7,0603,1/10W,±1%,RC0603FR-074R7L R7005
07-93309-00 Chip Resistor 33,0603,1/10W,±1%,RC0603FR-0733RL
R7032, R7044, R7045, R7050, R7051, R7052,
R7053, R7054, R7055, R7056, R7057, R7058,
R7059, R7060, R7061, R7062, R7063, R7066,
R7068, R7111, R7112, R7113, R7114, R7115
07-93909-00 Chip Resistor 39,0603,1/10W,±1%,RC0603FR-0739RL R7027, R7028
07-91000-00 Chip Resistor 100,0603,1/10W,±1%,RC0603FR-07100RL R7129, R7120
07-90121-00 Chip Resistor 120,0603,1/10W,±5%,RC0603JR-07120RL R7015, R7019, R7020
07-91500-00 Chip Resistor 150,0603,1/10W,±1%,RC0603FR-07150RL R7007
07-91501-00 Chip Resistor 1.5K,0603,1/10W,±1%,RC0603FR-071K5L R7043
07-90222-00 Chip Resistor 2.2K,0603,1/10W,±5% R7036, R7037
07-93091-00 Chip Resistor 3.09K,0603,1/10W,±1%,RC0603FR-073K09L R7035
07-90472-00 Chip Resistor 4.7K,0603,1/10W,±5%,RC0603JR-074K7L R7009, R7010, R7102, R7103
07-91002-00 Chip Resistor 10K,0603,1/10W,±1%,RC0603FR-0710KL R7016, R7110, R7119
07-93602-00 Chip Resistor 36K,0603,1/10W,±1%,RC0603FR-0736KL R7048
07-94702-00 Chip Resistor 47K,0603,1/10W,±1%,RC0603FR-0747KL R7022, R7023
07-91003-00 Chip Resistor 100K,0603,1/10W,±1%,RC0603FR-07100KL R7012, R7014, R7199
07-90000-01 Chip Resistor 0, 0805, ±5% R7000, R7001, R7327, R7328
07-91009-01 Chip Resistor 10,0805,1/10W,±1%,RC0805FR-0710RL R7065, R7067
07-91000-01 Chip Resistor 100,0805,1/8W,±1% R7126
07-92001-01 Chip Resistor 2K,0805,1/8W,±1% R7003
07-91002-01 Chip Resistor 10K,0805,1/8W,±1% R7329
07-91052-01 Chip Resistor 10.5K,0805,1/8W,±1%,RC0805FR-0710K5L R7002
07-95362-01 Chip Resistor 53.6K,0805,1/8W,±1%,RC0805FR-0753K6L R7008
07-91153-01 Chip Resistor 115K,0805,1/8W,±1% R7006
07-93323-01 Chip Resistor 332K,0805,1/8W,±1%,RC0805FR-07332KL R7004
07-91008-02 Chip Resistor 1,1206,1/4W,±1% R7042
07-90820-10 Chip Resistor NET 82,0603X4,±5%,YC164-JR-0782RL R7024, R7038((?), R7040(?), R7041(?)
07-90121-10 R Networks 120R,0603X4,1/10W,±1% R7013, R7026, R7046
Connector
11-04101-05 TACT SW IT-1102A-1160 SW7000
13-12510-22 Connector Socket
2x5Pin,
CNT-M254-2*5-GS-5.8/3-N
J7002
17-08001-02 USB connector GL56S08-04B J7003
17-08001-07 USB Socket UAR20-4W2100/GL56S05 J7001
13-12506-15 Connector Socket
2x3Pin,
CNT-M254-2*3-GS-5.8/3-N
J7000
Capacitor
06-22160-05 Alu Electrolytic Capacitor HCN,6V3,220uF,±20%,F3.5 C7000, C7012
06-10121-11 Alu Electrolytic Capacitor
CD284, 100uF, 25V, ±20%, 105ć, F2.5
C7008
06-33121-06 Alu Electrolytic Capacitor CD289,330uF,25V,±20%, C7004
01-39009-00
PCB
