NAD c390dd - C390 DD Bill of Materials; DIODES; TRANSISTORS; IC

∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
A16-39009-21 Power AMP PCB
DIODES
33-50603-04 SUPER BRIGHT ORANGE SML-311YTT86 D5
33-20540-02 SCHOTTKY DIODE B540C-13-F D3
33-20313-01 DIODE S3DB-13-F
D2, D11_CHLF, D11_CHRF, D12_CHLF,
D12_CHRF, D21, D22
33-40054-00 SCHOTTKY DIODE BAT54S
D1, D13_PSL, D13_PSR, D17_PSL, D17_PSR,
D305_CHL, D305_CHR
33-40054-02 Schottky Rectifier Diode BAT54J D18, D20 , D23
33-40099-02 Switch Diode BAV99-7-F
D7, D14_PSL, D14_PSR, D19_PSL, D19_PSR,
D301_CHL, D301_CHR, D304_CHL, D304_CHR,
D307_CHL, D307_CHR
33-20001-03 ULTRAFAST RECTIFIER ES1D D300_CHL, D300_CHR
33-22000-01 SCHOTTKY DIODE ZHCS2000TA D4, D6, D8, D15
33-00400-01 SCHOTTKY DIODE ZHCS400TA D9, D10
33-12009-10 Zener Diode 2V, 1/2W, LL34 D16
33-13309-09 Zener Diode BZX84C3V3-7-F,3.3V,0.35W D302_CHL, D302_CHR
33-15109-02 Zener Diode BZX84C5V1-7-F,5.1V,0.35W D303_CHL, D303_CHR, D306_CHL, D306_CHR
TRANSISTORS
31-00493-00 Transistor FZT493 Q10
31-00846-07 Transistor BC846B-7-F Q3, Q4, Q6, Q8, Q12
31-00856-07 Transistor BC856B-7-F Q2, Q7
31-00114-05 Digital transistor DTC114EKA Q5
31-00593-00 Transistor XSTR,FMMT593,PNP,100V Q304_CHL, Q304_CHR
31-07002-01 JFET 2N7002 Q100,Q101,Q102,Q103
31-00003-01 Dual FET ZXMC3AMCTA
Q1, Q300_CHL, Q300_CHR, Q302_CHL,
Q302_CHR
31-01015-03 Transistor A1015, SOT23 Q9, Q15, Q16
31-01815-03 Transistor C1815, SOT23 Q11, Q13, Q14, Q17, Q18
IC
03-20040-01 DDFA Advanced Feedback Processor ZXCZA200JC40TA U1
03-00800-02 DDFA Modulator ZXCZM800QPATR U3
03-28502-01 Zetex Voltage Reference ZR285F02TA REF1
03-00082-01 OP-AMP TL082BCD/TL082BCDR
U500_PSL, U500_PSR, U501_PSL, U501_PSR,
U502_PSL, U502_PSR
03-05004-13 PWM CONTROL 2.5A STEP-DOWN CONVERTER AP5004SG-13 U2
03-01117-09 Adjustable voltage regulator ZLDO1117GTA U8, U19, U20, U21, U22, U23
03-01100-01 Coupler digital isolator ADUM1100ARZ U300_CHL, U300_CHR
03-00337-01 3-Terminal Regulator LM337IMP, SOT223 U25
03-07865-01 TinyLogic ULP-A 2-Input Exclusive-OR Gate NC7SV86P5X U12, U16
03-07125-01 Buffer NC7SZ125P5X U11
03-07178-01 Tinylogic Triple Buffer with Schmitt Trigger NC7NZ17K8X
U5, U10, U13, U14, U15, U301_CHL, U301_CHR,
U302_CHL, U302_CHR
03-00774-02 D-Type Flip-Flop NC7SZ74K8X U7
03-01806-01 OP-AMP LT1806CS6 U9
03-49710-01 OP-AMP LME49710MA/NOPB U4, U6
03-00339-04 Quad Differential Comparators LM339ADR U100
03-04040-25 Precision Micropower shunt voltage reference LM4040DIM3-2.5 NOPB U101,U102
