NAD c390dd - Page 31

∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
07-92208-02 Chip resistor 1206, 2R2, 1% R137
07-91009-02 Chip resistor 10,1206,1/4W,±1%,RC1206FR-0710RL R164 R165
07-92009-02 Chip resistor 20,1206,1/4W,±1%,RC1206FR-0720RL R146 R163
07-90221-02 Chip resistor 1206, 220R, 5% 0,25W R147 R148
07-90471-02 Chip resistor 470R, 1206, 5% R108 R114
07-90513-02 Chip resistor 51K,1/4W,±5%,RC1206JR-0751KL R109 R115
07-90154-02 Chip resistor 150K,1206,1/4W,±5%,RC1206JR-07150KL R120 R121
07-93307-16 Chip resistor 2512, 0R33, 1%, 2W R156 R157 R158
07-96201-06 Chip resistor 2512, 6k2, 1%, 2W R124 R125 R126 R127
DIODES
33-25406-00 diodes 1N5406RL D105
33-23006-00 diodes 30ETH06PBF D106
or 33-22906-00 diodes DSEP 29-06A D106
33-21620-00 Rectifier Diode MUR1620 D112 D113 D114 D115
33-32542-00 BRIDGE RECTIFIER TS25P05G, 25A/420VRMS BR101
TRANSISTOR
31-02878-00 transistor 2SC2878 Q100 Q101
31-01850-03 N-Channel MOSFET FDP18N50 Q104 Q105 Q106
IC
31-05064-00 THYRISTOR 2N5064 TSG100 TSG102
31-06402-00 THYRISTOR 2N6402 TSG101 TSG103
25-10542-00 Metallize Polyester MMK22.5, 105K400D15L4 C115
25-10542-01 Miniaturized polypropylene film Cap
MKP21-400V-105J,1uF,400Vdc,±5%,W 26.5,H
20,T 11,P 22.5
C116 C117
25-68342-01 Miniaturized polypropylene film Cap CBB21-400V-683K C120 C121
25-10561-02 Metallized Polyester Film Capacitor CL23B-63V-105J RA C104 C105
A25-33422-00 Interfernece Suppression Cap MKP62, 330nF, 275VAC, X2, ±10% CX100
A25-22522-05 Interfernece Suppression Cap MPX, 2.2uF, 275V, ±10%, PX225K3IE89H200DR CX102
A25-10422-07 Interfernece Suppression Cap MPX,0.1uF/275V,13mm*6mm,10%,Pitch=10mm CX101
A05-22242-00 High Voltage Ceramic Capacitor CT81-400VAC-08b-2E4-222M-YA CY102
06-10051-02 Alu Electrolytic Capacitor CD263(X), 10uF, 50V, ±20% C112
06-22281-04 Alu Electrolytic Capacitor
2200uF, 80V, ±20%,105ć
C126 C127 C128 C129
06-22142-04 Alu Electrolytic Capacitor
CD29C,220uF,450V,±20%,105ć
C118 C145
RESISTOR
07-40100-10 Ceramic Resistor 10,10W,±5%,Pitch=5mm R112 R113 R118 R119
07-30151-12 Metal Oxide film Resistor RY21, 150, 2W, ±5% R111 R117
07-30132-03 Metal Oxide film Resistor RY21, 1.3K, 3W, ±5% R110 R116
07-30104-06 Metal Oxide film Resistor
RY21, 100K, 2W, ±5%,Pitch=5mm ゟᓣ
R123
A07-72381-00 NTC SG64, NTC_SG64/265VAC NTC100
A07-70471-01 TVS HEL-14D471K ZV100
INDUCTOR
22-00100-03 INDUCTOR I32L10UH, 10uH ±10% L103
22-00025-09 common mode line chokes
LE-T25M, ı8mH
L101
08-05541-00 common mode line chokes HJ-I22-PFC-L,540uH L102
A22-04215-00 Transformer HJ-C390EER4215 T102
22-00013-01 Transformer TS-T13B T100
22-01050-00 Current CS1050L T101
RELAY
A12-01101-00 POWER RELAY JZC-36F 005-HSLT K100 K101
or A12-03101-11 POWER RELAY STD-S-105-LMR2, 5Vac TV-5 K100 K101
