C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
CONNECTOR
13-22502-14 Jumper Cap
2Pin
CNT-MJ254-02-O
CON100 CON102
13-12502-19 Connector
2Pin,
CNT-M254-1*2-GS-5.6/3-N
CON100 CON102
13-22502-00 Connecter XHB 2.54A-2A J103
13-22505-00 Connecter XHB 2.54A-5A J102
13-23903-01 Connecter VH 3.96A-3A J100
84-006001-0 Cable Tie YJ-163 Ties to L102
01-39011-00 PSU B BOARD
PCB
A16-39011-21 PSU-B
DIODES
33-20007-00 Diode M7A D202
33-20120-01 DIODE SMD MURS120T3G D200 D210
33-20036-00 Schottky Rectifier Diode SS36B D209
33-30062-00 BRIDGE RECTIFIER B6S, 0.8A 600V D207
33-11800-30 Zener Diode 18V, 3W, ±5%, SMB DW200, DW201
IC
03-00431-11 Regulator TL431BCDBZTG4 IC201 IC202
03-61562-01 Photo Transistor SFH6156-2T OP200 OP202 OP203
A03-00817-03 Photo Coupler PC817X2NIP OP201
Capacitor
26-10151-01 Chip capacitor 0805, 100PF, 50V, NPO C207 C208
26-10451-11 Chi
p
ca
p
acito
r
0805
,
100nF
,
50V
,
X7
R
C201 C202 C203 C214 C215 C216 C224 C22
5
26 10451 11
Chip
capacitor
0805
,
100nF
,
50V
,
X7R
C201
C202
C203
C214
C215
C216
C224
C225
26-22451-11 Ceramic Chip Capacitor 220nK,50V,0805,X7R C218
26-10212-02 SMT Capacitor 1nF, 100V, X7R, ±10% C209
RESISTOR
07-96808-01 Chip resistor 6.8, 0805, 1/8W,1% R217
07-91009-01 Chip resistor 0805, 10R, 1% R218
07-91000-01 Chip resistor 0805, 100R, 1% R212
07-93300-01 Chip resistor 330,0805,1/8W,±1%,RC0805FR-07330RL R207, R219
07-91001-01 Chip resistor 0805, 1K, 1% R202 R203 R204 R206
07-92201-01 Chip resistor 0805, 2.2K, 1% R223 R226 R227
07-93001-01 Chip resistor 0805, 3K, 1% R222
07-97501-01 Chip resistor 0805, 7.5K, 1% R216
07-91002-01 Chip resistor 0805, 10K, 1% R200 R201
07-91202-01 Chip resistor 0805, 12K, 1% R221
07-92202-01 Chip resistor 0805, 22K, 1% R224 R225
07-95602-01 Chip resistor 56K,0805,1/8W,±1%,RC0805FR-0756KL R220
07-90101-02 Chip Resistor 100,1206,1/4W,±5% R210 R211
07-90121-02 Chip Resistor 120,1206,1/4W,±5% R208
07-90684-02 Chip resistor 1206, 680K, 5% R213 R214 R215
DIODES
33-24006-00 Rectifier Diode UF4006 D204 D205 D206
33-26200-00 TVS P6KE-200A D208
33-21620-00 Rectifier Diode MUR1620 D201
33-30682-00 BRIDGE RECTIFIER GUB608 D203
TRANSISTOR
31-00647-01 Transistor 2SB647-D Q200
IC
03-00246-00 Power control IC TOP246Y IC200
03-00274-00 Power control IC TNY274PN IC203
03-07815-08 Voltage Regulators KA78R15CTU U200
Capacitor
25-10342-00 Metallized Polyester Film Capacitor CL23B-400V-103K RA C206
A05-22242-00 High Voltage Ceramic Capacitor CT81-400VAC-08b-2E4-222M-YA CY200 CY201
