C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
06-47042-01 Alu Electrolytic Capacitor
CD263,47uF,400V,±20%,105ć
C212
06-10042-00 Alu Electrolytic Capacitor CD11H, 10uF, 400V, ±20% C220
06-10051-02 Alu Electrolytic Capacitor CD263, 10uF, 50V, ±20%, Pitch=2.5mm C217 C223
06-47021-02 Alu Electrolytic Capacitor CD263(X), 47uF, 25V, ±20% C213
06-47051-06 Alu Electrolytic Capacitor CD263,47uF,50V,±20%,6.3×11,F2.5 C219
06-10211-05 Alu Electrolytic Capacitor
CD263X,1000uF,10V,±20%,105ć,F5.0
C221 C222
06-10221-01 Alu Electrolytic Capacitor CD263(X), 1000uF, 25V, ±20% C210 C211
06-10121-11 Alu Electrolytic Capacitor
100uF, 25V, ±20%,105ć
C204 C205
RESISTOR
07-30473-02 Metal Oxide film Resistor 47K, 2W, ±5% R205
07-70050-02 NTC 5D-11 TH200
INDUCTOR
19-35980-00 Inductor
FB F10 RHW 3.5*8.3*0.8-T, 䭓ᓩ㒓
L200
08-02100-07 INDUCTOR 10uH, 2.6A,744772100 L204
08-05220-01 INDUCTOR 22uf L203
A22-00025-14 Transformer HJ-C390EEL25 T200
A22-00016-13 Transformer HJ-C390EE16 T201
Relay
12-01101-19
㒻⬉఼
HF36F/012-HST(555), TV-5 K200
01-39002-00 SPK BOARD
PCB
A16-39002-22 C390DD SPK PCB
26-47122-02 Ceramic Chip Capacitor 470PJ,200V,1206,NPO
C932, C934, C936, C938, C940, C942, C944,
C946, C948, C950, C952, C954, C956, C958,
C960, C962, C964, C965, C966, C967, C968,
C969, C970, C971, C972, C973, C974, C975,
C976, C977, C978, C979
INDUCTOR
22-01626-00 Transformer T16*9*5-4TS L901, L902
CONNECTOR
32-26308-06 PCB Terminal 6.3-1, HS4-CI9120-B009V1-M032
J2, J4, J5, J6
69-230001-0 Leaf Spring
䪡䪰QBe2.0 T=0.2mm,㸼䴶䩱࣪໘⧚
01-39013-00 Bootload BOARD
PCB
A16-39013-21
C390DD BootloadǂPCB
Capacitor
26-10611-01 Ceramic Chip Capacitor
10uF,0805,10V,C0805C106M8PACTU/C2012X5R1
A106M
C902
26-10351-01 Ceramic Chip Capacitor 10nK,50V,0805,X7R C901
esistor
07-91009-01 Chip Resistor 10,0805,1/10W,±1%,RC0805FR-0710RL R951
Diode
33-40352-01 Switch Diode 1SS352(TPH3,F),1SS355TE-17 D951,D952
