NAD C715 - Page 64

POWER PCB ASS'Y
(
DABC : COP12019B, C : COP12019C, AH : COP12019D
)
CUP12019Z PCB , POWER C715(240X251, FR-1)
REF NO. PART NO. DESCRIPTION REMARKS
CUP12018-1 USB BOARD
BN83 CWZC715BN83 SHIEL WIRE ASS'Y
(
5P, 250MM
)
C821 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
JK83 HJJ9X001Z JACK, USB
REF NO. PART NO. DESCRIPTION REMARKS
CUP12018-2 PHONE BOARD
BK85 CMC1A324 BRACKET , JACK C715
BN41 CWB2B005180EN WIRE ASS'Y
(
5P, 180MM
)
BN51 CWZC715BN51 SHIEL WIRE ASS'Y
(
3P, 400MM
)
C816 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C818 HCBS1C472MXT CAP , CERAMIC 4700PF 16V M
C819 HCBS1C472MXT CAP , CERAMIC 4700PF 16V M
JK81 CJJ2E028Z JACK , HEADPHONE
(
3.5mm, GOLD
)
PJ-323AG-7
JK82 CJJ2E028Z JACK , HEADPHONE(3.5mm, GOLD) PJ-323AG-7
REF NO. PART NO. REMARKS
CUP12018-3 FRONT BOARD
BK83 CMD1A468 BRACKET , FLT
BK84 CMD1A468 BRACKET , FLT
C801 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z
C802 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z
C803 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z
C804 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z
C805 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C806 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C807 HCBS1H221KBT CAP , CERAMIC 220PF 50V K
C808 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C809 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C810 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C811 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C812 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C813 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C814 HCBS1H390JT CAP , CERAMIC 39PF 50V J
C817 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C820 CCEA1CH470T CAP , ELECT 47UF 16V
CN81 CJP17GB113ZY WAFER
D801 CVD50BOBBWGA L.E.D , 2 COLOR
(
ORG , BLUE
)
TOL-50BOBBWGA
D802 CVD1N4003ST DIODE , RECT 1N4003
FIP1 HFLHCA-17SM03T FIP
JW83 CWE8102080RV WIRE
(
1P
)
JW84 CWE8102080RV WIRE
(
1P
)
Q209 HVTKRA107MT T.R KRA107M
Q210 HVTKRC107MT T.R KRC107M
R801 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R802 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R803 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R804 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J
R805 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R806 CRD20TJ182T RES , CARBON 1.8K OHM 1/5W J
R807 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R808 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R809 CRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R812 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
R813 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R814 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R815 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R816 CRD20TJ822T RES , CARBON 8.2K OHM 1/5W J
R817 CRD20TJ330T RES , CARBON 33 OHM 1/5W J
R818 CRD20TJ330T RES , CARBON 33 OHM 1/5W J
R819 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R820 CRD20TJ330T RES , CARBON 33 OHM 1/5W J
R821 CRD25TJ272T RES , CARBON 2.7K OHM 1/4W J
R822 CRD20TJ271T RES , CARBON 270 OHM 1/5W J
RC81 CRVKSM603TH2E SENSOR , REMOCON KSM603TH2E
S801 CST1A012ZT SW , TACT SKHV10910G
S802 CST1A012ZT SW , TACT SKHV10910G
S803 CST1A012ZT SW , TACT SKHV10910G
S804 CST1A012ZT SW , TACT SKHV10910G
S805 CST1A012ZT SW , TACT SKHV10910G
S806 CST1A012ZT SW , TACT SKHV10910G
S807 CST1A012ZT SW , TACT SKHV10910G
S808 CST1A012ZT SW , TACT SKHV10910G
S809 CST1A012ZT SW , TACT SKHV10910G
S810 CST1A012ZT SW , TACT SKHV10910G
S811 CST1A012ZT SW , TACT SKHV10910G
VR81 CSR2A036Z ENCODER VR
DESCRIPTION
3-8
