NAD C715 - Page 65

REF NO. PART NO. REMARKS
CUP12018-4 SPEAKER BOARD
BN31 CWB2B005050EN WIRE ASS'Y
BN62 CWB1C005200BM WIRE ASS'Y
(
5P, 200MM
)
C303 HCQI1H682JZT CAP , MYLAR 6800PF 50V J
C304 HCQI1H682JZT CAP , MYLAR 6800PF 50V J
C305 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
C306 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z
CN53 CJP05GA01ZY WAFER
(
YMW025-05R
)
R305 CRG1ANJ391H RES , METAL OXIDE FILM 390 OHM 1W J
R306 CRG1ANJ391H RES , METAL OXIDE FILM 390 OHM 1W J
R307 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
R308 CRD20TJ473T RES , CARBON 47K OHM 1/5W J
RY72 HSL4A004ZU RELAY OSA-SS-212DM3
SP31 CJJ5P012Z TERMINAL , SPEAKER
REF NO. PART NO. REMARKS
CUP12018-5 POWER BOARD
AT21 CJJ3G012Z TERMINAL , ANT DAB RF - 055A C715DABC ONLY
BK21 CMD1A387 BRACKET , PCB
BK22 CMD1A387 BRACKET , PCB
BN23 CJP44TT153ZY PIN , HEADER DAB
(
2.00MM
)
DAB2025 C715DABC ONLY
BN25 CWB2B005250EN WIRE ASS'Y
BN26 CJP02TT155ZY PIN , HEADER
(
2.54MM
)
DAB2025 C715DABC ONLY
BN53 CWB1C005100BM WIRE ASS'Y
(
5P, 100MM
)
BN94 CWB1C011150BM WIRE ASS'Y
(
11P, 150MM
)
C201 CCME2A104JXT CAP , METALLIZED FILM HMFS104J2AP050T
C202 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C203 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C204 CCET1HKLH332KK8 CAP , ELECT 3300UF 50V
C205 CCET1HKLH332KK8 CAP , ELECT 3300UF 50V
C206 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C207 HCQI1H103JZT CAP , MYLAR 0.01UF 50V J
C208 CCEA1HH4R7T CAP , ELECT 4.7UF 50V C715DABC ONLY
C209 CCEA1HH4R7T CAP , ELECT 4.7UF 50V C715DABC ONLY
C210 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z C715DABC ONLY
C211 CCEA1CH470T CAP , ELECT 47UF 16V C715DABC ONLY
C212 CCEA1CH470T CAP , ELECT 47UF 16V C715DABC ONLY
C213 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z C715DABC ONLY
C214 CCEA1AH471T CAP , ELECT 470UF 10V C715DABC ONLY
C215 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z C715DABC ONLY
C216 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z C715DABC ONLY
C217 CCEA1CH101T CAP , ELECT 100UF 16V C715DABC ONLY
C219 CCEA1AH471T CAP , ELECT 470UF 10V C715DABC ONLY
C220 CCEA1CH101T CAP , ELECT 100UF 16V
C221 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z
C223 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C224 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C225 CCEA1CH102E CAP , ELECT 1000UF 16V
C226 CCEA1CH102E CAP , ELECT 1000UF 16V
C227 CCEA1EH222E CAP , ELECT 2200UF 25V
C228 CCEA1EH222E CAP , ELECT 2200UF 25V
C229 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C230 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C232 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z
C233 CCEA1EH331T CAP , ELECT 33OUF 25V
C234 CCEA1CH101T CAP , ELECT 100UF 16V
C235 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C236 CCEA1EH471E CAP , ELECT 470UF/25V
C237 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C238 KCKDKS472ME CAP , CERAMIC
(
X1/Y2/SC
)
0.0047UF/2.5KV
C241 CCEA1EH102E CAP , ELECT 1000UF 25V C715DABC ONLY
C241 CCEA1EH331T CAP , ELECT 330UF 25V C715C, C715AH
C243 CCFT1H103ZF CAP , CERAMIC 0.01UF 50V Z
C245 CCFT1H103ZF CAP , CERAMIC 0.01UF 50V Z C715DABC ONLY
C246 CCEA1EH102E CAP , ELECT 1000UF 25V
C247 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
CN24 CJP08GA01ZY WAFER, STRAIGHT, 8PIN
CN91 CJP02KA060ZY WAFER
CN92 CJP02GA89ZY WAFER
CN93 CJP03GA90ZY WAFER
D201 HVDPBU604F DIODE , BRIDGE US PBU604F
D202 CVD1N4003ST DIODE , RECT 1N4003
D203 CVD1N4003ST DIODE , RECT 1N4003
D204 CVD1N4003ST DIODE , RECT 1N4003
D205 CVD1N4003ST DIODE , RECT 1N4003
D207 CVD1SS133MT DIODE 1SS133
D208 HVDMTZJ6.2BT DIODE , ZENER 6.2V
D209 CVD1SS133MT DIODE 1SS133
D210 CVD1N4003SRT DIODE , RECT 1N4003
D211 CVD1N4003SRT DIODE , RECT 1N4003
D212 CVD1N4003SRT DIODE , RECT 1N4003
DESCRIPTION
DESCRIPTION
3-9
