D213 CVD1N4003SRT DIODE , RECT 1N4003
D214 CVD1N4003ST DIODE , RECT 1N4003
D215 CVD1N4003ST DIODE , RECT 1N4003
D216 CVD1N4003ST DIODE , RECT 1N4003
D217 CVD1N4003ST DIODE , RECT 1N4003
ET91 CNE75 PLATE , EARTH
F751 KBA2C2000TLEZ FUSE T 2A L 250V C715DABC, C715C
F751 KBA2C3000TLUZ FUSE SB 3A 250V C715AH ONLY
IC21 HVI74HC4066D I.C , SWITCHING 74HC4066D C715DABC ONLY
IC91 CVIKIA7812A I.C , REGULATOR + 12V
IC92 CVIKIA7912A I.C , REGULATOR - 12V
IC93 CVIKIA7805A I.C , REGULATOR + 5V C715DABC ONLY
IC93 HVIKA78L05AZT I.C , REGULATOR + 5V C715C, C715AH
IC94 CVIKIA7805A I.C , REGULATOR + 5V C715DABC ONLY
IC95 HVILM1117S-ADJ I.C , REGULATOR LM1117-ADJ C715DABC ONLY
JK21 HJSTOTX177L MODULE , OPTICAL
(
TX
)
TOTX177L
Q201 HVTKRC107MT T.R KRC107M C715DABC ONLY
Q207 HVTKRC107MT T.R KRC107M
Q208 HVTKSC2316YT T.R KSC2316Y
R201 CRD25TJ183T RES , CARBON 18K OHM 1/4W J
R202 CRD25TJ183T RES , CARBON 18K OHM 1/4W J
R203 CRD20TJ473T RES , CARBON 47K OHM 1/5W J C715DABC ONLY
R204 CRD20TJ473T RES , CARBON 47K OHM 1/5W J C715DABC ONLY
R205 CRD20TJ391T RES , CARBON 20K OHM 1/5W J C715DABC ONLY
R206 CRD20TJ221T RES , CARBON 220 OHM 1/5W J C715DABC ONLY
R207 CRD20TJ103T RES , CARBON 10K OHM 1/5W J C715DABC ONLY
R208 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J C715DABC ONLY
R209 CRD20TJ102T RES , CARBON 1K OHM 1/5W J C715DABC ONLY
R210 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J C715DABC ONLY
R211 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J C715DABC ONLY
R213 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J C715DABC ONLY
R214 CRD20TJ562T RES , CARBON 5.6K OHM 1/5W J C715DABC ONLY
R216 HRDERC12UGK335T RES , CARBON ERC12UGK 3.3M OHM
R218 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J
R219 CRQ1AJR47H RES , FUSE
R220 CRQ1AJR47H RES , FUSE
R221 CRD25TJ183T RES , CARBON
R222 CRD25TJ183T RES , CARBON
R223 CRQ1AJR47H RES , FUSE
R224 CRQ1AJR47H RES , FUSE
RY71 HSL1D016ZE RELAY SDT-S-109DMR
T701 CLT5I002ZE TRANS , SUB
T701 CLT5I002ZU TRANS , SUB
WF21 CJP13GA117ZY WAFER , CARD CABLE
REF NO. PART NO. REMARKS
CUP12018-6 AMP BOARD
BK23 CMD1A387 BRACKET , PCB
BK24 CMD1A387 BRACKET , PCB
BN61 CWB2B003180EN WIRE ASS'Y
(
3P, 180MM
)
C603 CCEA1HH4R7T CAP , ELECT 4.7UF 50V
C604 CCEA1HH4R7T CAP , ELECT 4.7UF 50V
C607 CCEA1HH101T CAP , ELECT 100UF 50V
C608 CCEA1HH101T CAP , ELECT 100UF 50V
C621 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C622 CCEA1HH470T CAP , ELECT 47UF 50V
C623 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C624 CCEA1HH470T CAP , ELECT 47UF 50V
C625 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z
C627 HCQI1H682JZT CAP , MYLAR 6800PF 50V J
C628 HCQI1H682JZT CAP , MYLAR 6800PF 50V J
C631 CCME2A104JXT CAP , METALLIZED FILM HMFS104J2AP050T
C632 CCME2A104JXT CAP , METALLIZED FILM HMFS104J2AP050T
CN25 CJP05GA19ZY WAFER , STRAIGHT
CN62 CJP05GA01ZY WAFER
(
YMW025-05R
)
IC61 CVITDA7292 I.C , AMP 40WX2CH
L601 KLZ9H001Z BEAD , CORE
L602 KLZ9H001Z BEAD , CORE
R603 CRD25TJ183T RES , CARBON 18K OHM 1/4W J
R604 CRD20TJ183T RES , CARBON 18K OHM 1/5W J
R605 CRD25TJ102T RES , CARBON 1K OHM 1/4W J
R606 CRD20TJ102T RES , CARBON 1K OHM 1/5W J
R607 CRD25TJ822T RES , CARBON 8.2K OHM 1/5W J
R608 CRD25TJ822T RES , CARBON 8.2K OHM 1/5W J
R621 CRD20TJ104T RES , CARBON 100K OHM 1/5W J
R631 KRG1SANJ4R7RT RES, METAL
(
OXIDE
)
FILM,5% 4.7/1W
(
RADIAL
)
R632 KRG1SANJ4R7RT RES, METAL(OXIDE)FILM,5% 4.7/1W(RADIAL)
DESCRIPTION
