The following are all the possible decoding and post processing options for Dolby Digital
5.1 inputs with THX option turned on. See figure E
Notes: if the surround back speakers are set to "none" then THX Surround EX, PLIIx + THX
Cinema, and THX Ultra2 Cinema, will be skipped, but THX Cinema will then become
available.
if the surround back speakers are set to “1 LARGE” or 1 SMALL” then Dolby Surround
EX, PLII x Music and PLIIx Movie will be available.
The following are all the possible decoding and post processing options DTS 5.1 inputs
with THX option turned on. See figure F
Notes: if the surround back speakers are set to "none" then THX Surround EX, PLIIx + THX
Cinema, and THX Ultra2 Cinema, will be skipped, but THX Cinema will become
available.
The following are all the possible decoding and post processing options for DTS 6.1 ES
Discrete and Matrix inputs with THX option turned off. See figure G
The following are all the possible decoding options DTS 6.1 ES Discrete and Matrix inputs
with THX option turned on. See figure H
Note: if the surround speakers are set to "none" then THX Cinema will be skipped.
The following are all the possible decoding and post processing options for DTS 6.1 ES
Discrete inputs with THX option turned off..See figure G.
The following are all the possible decoding and post processing options for DTS 6.1 ES
Discrete inputs inputs with THX option turned on. See figure H
Note: if the surround speakers are set to "none" then THX Cinema will be skipped.
ABOUT THE M15
Identification of controls
THX Ultra2 Cinema
THX Surround EX
THX Cinema
THX Music Mode
PLIIx + THX Cinema
Dolby PLIIx Music
Stereo Downmix
Mono Downmix
Figure E
THX Ultra2 Cinema
THX Surround EX
THX Cinema
THX Music Mode
PLIIx + THX Cinema
Dolby PLIIx Music
Stereo Downmix
Mono Downmix
DIRECT
Stereo Downmix
Mono Downmix
Stereo Downmix
Mono Downmix
THX Cinema
Figure F
Figure G
Figure H
