Rear panel // power supply chassis
STATUS LED for software upgrade & detection of wrong audio device chassis
SUB-D9 for Home automation
REMOTE IN (1x) to be driven by “master” device
REMOTE OUT (4x) to drive “slave” devices
LEMO power supply outputs (Analog 9p, Digital 7p)
Mains appliance inlet with switch and fuse
+ voltage version & fuse value information
Ground post
About ground post
This feature is seldom used but can sometimes come in handy to solve specific setup
issues. Your NAGRA dealer will assist you on when and how to use this connector.
