IR Remote Control Unit
The HD PREAMP currently comes with the new IR Remote Control Unit with Philips RC-5
format encoding. You may also use a Nagra RCU or RCU-II IR Remote Control Unit.
As they require a different communication protocol (RECS-80), please contact your Nagra
dealer to make the necessary adjustments inside your HD PREAMP.
Red LED
Power OFF - ON // HD PREAMP
Numeric keyboard //CD track
Short press: track restart (CD) or Long press: fast backward (CD)
Volume up // HD PREAMP
Mute // HD PREAMP
Right balance on right volume control // HD PREAMP
Standard commands from left to right: PLAY, PAUSE, STOP (CD)
Direct input selection // HD PREAMP
Balance reset // HD PREAMP
Next input selection // HD PREAMP
Previous input selection // HD PREAMP
Left balance on right volume control // HD PREAMP
Volume down // HD PREAMP
Short press: next track (CD) or Long press: fast forward (CD)
HD PREAMP
CD
Note
To protect the Li battery in the device during transport,
the Remote Control Unit keys have been locked. To unlock
them, press on MUTE for 5 seconds until the red LED
blinks twice.
WARNING
The Remote Control Unit, with battery installed, must not be exposed to
excessive heat such as sunshine, fire or similar.
