Nakanishi E4000 CONTROLLER User Manual

58
6 - 3 Outside View of the CONTROLLER
Fig. 1 Bottom Mounting
Fig. 2 Vertical Mounting
*Below is an outside view with the Brackets attached (Standard Accessory).
45
80
276
296
224
110
100
155
120
10
5
290 250
36
4.5
10
36
350
278
330
250
100
80
290
4.54.5
10
45
CAUTION
Do not stack 2 CONTROLLERs on top of each other. This will increase the heat generated inside
the CONTROLLERS, leading to a premature failure.
