W415-3092 / 07.13.21

maintenance

To remove, slide the back edge of the door trim up and out of the glass and the door frame.

To install, slide the back edge of the door trim down between the glass and door frame. Insert downwards.

5.4 door trim removal

These spring latches make up the spring

relief system for the appliance. Ensure

the door opens freely and closes sealed.

note:

When mounting the door, ensure there

is equal space on both the left and the

right side. This allows for easy installation

of the front.

note:

BL46 illustrated

Leave a hand on the glass door during entire door removal. The glass door is secured to the ﬁrebox with four

(BL36-1) or six (BL46) spring latches. Pull the handles of the latches forward, then lift the latches out from the door

frame to release the door. Next, lift the door up until the bottom edge clears the bottom shoulder screws of the

appliance. Carefully grip the top and bottom of the door lifting it off the appliance.

Reverse these steps to reinstall the door.

Ensure safety screen is installed correctly.

5.5 ﬁrebox glass door removal
