EN
W415-1802 / A / 11.06.18
15
finishing
3.2 safety barrier & door removal / installation
A barrier designed to reduce the risk of burns from the hot viewing glass is provided with the
appliance and must be installed.
1. Before the glass door can be removed, the safety barrier must be removed. Lift the safety barrier from
the 4 tabs, tilt the top forward, and remove from the appliance (Fig. 1 and 2).
2. Release the top left and right door latches, located at the top of the door (Fig. 3). Tilt forward and lift
from slots.
3. Reverse these steps to re-install the safety barrier and glass door. Ensure safety barrier is installed
correctly.
• Glass may be hot. Do not touch glass until cooled.
• If equipped with door latches that are part of a safety system, they must be properly engaged. Do not
operate the appliance with latches disengaged.
• Facing and/or fi nishing materials must not interfere with air fl ow through air openings, louvre openings,
operation of louvres, or doors/access for service. Observe all clearances when applying combustible
materials.
• Before door is removed, turn the appliance off and wait until appliance is cool to the touch. Doors are heavy
and fragile so handle with care.
SAFETY BARRIER
Fig. 1
Fig. 2
note:
If applicable, the optional front must be removed to allow the door to be opened or closed.
Fig. 3
