W415-1802 / A / 11.06.18
EN
6
general information
1.1 rates and efficiencies
NG P
Altitude (FT) 0 - 4500FT 0 - 4500FT
Max. Input (BTU/hr) 24,500 24,500
Max. Output (BTU/hr) 13,475 13,475
P4 55.0% 55.0%
GDI3
NG P
Altitude (FT) 0 - 4500FT 0 - 4500FT
Max. Input (BTU/hr) 24,000 24,000
Max. Output (BTU/hr) 14,808 14,808
P4 61.7% 61.7%
GDIG3
NG P
Altitude (FT) 0 - 4500FT 0 - 4500FT
Max. Input (BTU/hr) 30,000 30,000
Max. Output (BTU/hr) 18,540 18,540
P4 61.8% 61.8%
GDIX3
NG P
Min. Inlet Gas Supply Pressure 4.5" W.C. (11mb) 11" W.C. (27mb)
Max. Inlet Gas Supply Pressure 7" * W.C. (17mb) 13" W.C. (32mb)
Manifold Pressure (under Flow Conditions) 3.5 W.C. (9mb) 10" W.C. (25mb)
GDI3 / GDIG3 / GDIX3
* Max. inlet pressure not to exceed 13".
