EN
W415-1802 / A / 11.06.18
39
replacement parts
6
5
4
1
3
5
4
3
1
2
Items may not appear exactly as illustrated
FIREBOX TOP ASSEMBLY
Ref. No.
Stocked
Part number
Description
1
W010-3684
Door latches (X2)
2
3
W405-0072
High temperature light assembly
4
W290-0080
Cover plate gasket
5
W300-0086
Ceramic glass lens
W280-0071
Lens frame
Yes
Yes
Yes
7.6 firebox top assembly
