4-24 Description
4.10.2 EHP-TS Settings The Standard section allows the user to select one of the standard
ICNIRP or EU limits for occupational or general public exposure, already
included by the software installation.
In the Mode section you can select Electric 1 kV/m or Electric 100 kV/m or
Magnetic 100uT or Magnetic 10mT.
The Span section displays the frequency range, which is always full range
1 Hz to 400 kHz in Weighted Peak Mode.
The Data section allows the user to read the measurements for the highest
peak and Marker, to choose the axis and set the desired Hold Time.
