4-2 Description
4.2 EHP50-TS
Application
4.2.1 Main menu
This chapter describes controls and functions provided by the EHP50-TS
application for time domain and spectrum analysis, included in EHP-TS
software package.
Connect EHP-50F to the USB port of your PC using provided optical fibre
and USB-OC optical to USB converter. Optional 8053-OC optical to RS232
converter can be used, as an alternative, to connect the analyzer to the PC
RS232 connector.
Switch the analyzer ON and run EHP50-TS application; a welcome
screenshot will appear for a few seconds.
If the stored Firmware and/or FPGA version is older than what is
available, the software will inform you that an update is needed.
Confirm with OK and the Firmware/FPGA updating utility will be
automatically run (for further information please see chapter 7).
Otherwise the program EHP-TS main window will be shown:
Fig.4-1 EHP50-TS Main Window
