Appendix B Hardware Configuration
NI 8352/8353 User Manual B-16 ni.com
Table B-7 shows all possible memory module combinations.
Installing memory with different speeds is allowed, but the faster memory
downshifts to the speed of the slower memory.
VGA memory 16 MB 2.85
TSEG 1 MB 2.84
Memory available to OS and other
applications
— 2.84
Table B-7. Memory Module Combinations
DIMM1
(Channel A)
DIMM2
(Channel B)
DIMM3
(Channel A)
DIMM4
(Channel B)
Total Memory
256 MB–2 GB 256 MB–2 GB — — 512 MB–4 GB
— — 256 MB–2 GB 256 MB–2 GB 512 MB–4 GB
512 MB–1 GB 512 MB–1 GB — — 1–2 GB
512 MB–1 GB 512 MB–1 GB 512 MB–1 GB 512 MB–1 GB 2–4 GB
Table B-6. Possible System Memory Allocation and Availability (Continued)
System Device Size
Physical Memory Available
(4 GB Total System Memory)
